Toyota MK2 1996 | Wheel & Coil Over Set-up | Recommendations/discussion

Posted: 20/07/21 10:46
by BigAL
Hello everyone! i have a 1996 Blue Toyota MR2 MK2 and it's my pride and joy!

After spending a hefty sum to get it completely rust free im wanting to upgrade its current stock set up to what I'm thinking is BC Racing Coil-overs and a pair of JR Wheels JR7's

I'm writing In here for some help and guidance really and just curious to see what you lovely people are running and what you have found to be the best fitment!

I'm a novice when it comes to this kinda stuff with sizing etc! so i would really appreciate any recommended sizing and set up :D

Im thinking - J

R Wheels JR7 17x8 ET35 5x114.3 - FRONT
R Wheels JR7 17x9 ET35 5x114.3 - REAR
BC Racing Coilovers for Toyota MR2 SW20\21 90-99

Cheers everyone!

Re: Toyota MK2 1996 | Wheel & Coil Over Set-up | Recommendations/discussion

Posted: 21/07/21 0:42
by peteV6R5
I had BCs on my V6 loved them
wheels had sparco NS2 Crimsons 17"
Fronts 17/8/ET32 with 215/40/17s
rears 17/9/ET35 with 245/40/17s
perfect fit

Re: Toyota MK2 1996 | Wheel & Coil Over Set-up | Recommendations/discussion

Posted: 21/07/21 10:00
by BigAL
Awsome, thanks Pete!! nice fit!

Re: Toyota MK2 1996 | Wheel & Coil Over Set-up | Recommendations/discussion

Posted: 21/07/21 12:40
by nick
Agree re BC's.

Re: Toyota MK2 1996 | Wheel & Coil Over Set-up | Recommendations/discussion

Posted: 22/07/21 13:28
by TonyleFrog
More BCs. :)

@BigAL, you don't mention whether your car is a turbo or n/a.
That is relevant because BCs have two different spring rates.
Front 4kg/mm Rear 6kg/mm & Front 5kg/mm Rear 8kg/mm
Have a look at this thread - https://mr2oc.co.uk/forum/41/159862.html

With a 9J ET35 rear, arch rolling might be needed depending on your ride height setting.
Coilovers make adjusting that a straightforward task.

Re: Toyota MK2 1996 | Wheel & Coil Over Set-up | Recommendations/discussion

Posted: 22/07/21 13:52
by nick
With my N/A I went for the lower spring rates. Still a decent ride. Higher ones would be pretty stiff for an N/A
